LD20 Three Roller Stell Rolling Mill for Seamless Tube Making

LD20 Three Roller Stell Rolling Mill for Seamless Tube Making

    • LD20 Three Roller Stell Rolling Mill for  Seamless Tube Making
    • LD20 Three Roller Stell Rolling Mill for  Seamless Tube Making
  • LD20 Three Roller Stell Rolling Mill for  Seamless Tube Making

    Product Details:

    Place of Origin: China
    Brand Name: Hengli
    Certification: ISO2000
    Model Number: LD20

    Payment & Shipping Terms:

    Minimum Order Quantity: 1
    Packaging Details: The machine must be entirely rust proof coated and painted using good quality rust proof coat and paint then oiled and packed in plastic to avoid rusting at sea. machine should be on wooden planks.
    Delivery Time: 60 days
    Payment Terms: TT/LC
    Supply Ability: 20 sets/month
    Contact Now
    Detailed Product Description
    Machine Type: LD20 Cold Pilger Mill Hollow Tube OD: 10mm--22mm
    Hollow Tube WT: 0.5mm--2mm Finished Tube OD: 8mm--20mm
    Finished Tube WT: 0.3mm--1.5mm
    High Light:

    steel rolling mill machinery

    ,

    two high rolling mill





    Triple Roll Steel Rolling Mill , Cold Drawn Seamless Tube Making Machine





    Features and application



    1.Suitable for mild steel, stainless steel, and special steel, especially for high precision wider and thin coils.

    2.That hydraulic bending devices and middle rolles horizontal moving installations can fast regulate the roller's in order to eliminate the harmful touching areas of rollers to aim to control the plate shape and gibbous degree.



    3.Flat,stability, and controllable. It's effective to improve thinner of strip edges and cracks with smaller working rollers to enhance pressure force and total pressure force of rolling routes. Type of working rollers is flat rollers which reduce the requirement of spare parts and consumption.



    4.It is equipped with AGC system to get high precision, which is especially suitable for rolling hih precision requirement of wider coils and thinner coils.



    Applications:



    Be used in the field of Carbon pipes,Non-ferrous metal pipes,and so on.

    Detailed Product Description



    No.

    Name

    LD20



    1

    Shell OD(mm)

    10~22

    mm

    2

    Shell WT(mm)

    <2

    mm

    3

    Shell Length(mm)

    4

    mm

    4

    Finished tube OD(mm)

    8~20

    mm

    5

    Finished tube WT(mm)

    0.1~1.5

    mm

    6

    Finished tube Length(m)

    8

    m

    7

    Stroke Frequency of Mill time/min

    60~120

    time/min

    8

    Stroke of Rolling mill bus(mm)

    415

    mm

    9

    Feeding Length(mm)

    1.65~7.1

    mm

    10

    rotation angle

    52°



    11

    Roll Diameter(mm)

    54.7

    mm

    12

    Power(KW)

    22

    KW

    13

    Size

    (L×W×H)

    19×2×1

    m





    Additional features



    Technical Documents



    All labels on machines and layout drawings, electrical diagram, operated manual will be English and will be offered by manufacturer after machine transported.
